120W Solar Panel for Security Camera
- 120W High‑efficiency Mono Silicon Solar Panel for Outdoor Security Monitoring
- Top Grade Mono Cells, Conversion Efficiency Up to 22.8%
- 9.8kg Heavy‑duty Aluminum Alloy Frame Construction
- Adjustable Mount Bracket for Optimal Sunlight Capture
- High‑transparency Tempered Glass for Harsh Outdoor Conditions
- Standard MC4 Connector, 300mm Cable Length (Customizable Available)
- Stable 36V Output, Max 5.56A Charging Current
- IP68 Dustproof & Waterproof Outdoor Performance
- Wide‑25℃ ~ +65℃ Stable Operating Temperature
- -0.4%/℃ Power Temperature Coefficient for Real‑world Output Reliability
- ISO/CE/FCC/RoHS Multi Safety Certifications
- Rugged Aluminum Alloy Frame & High‑transparency Tempered Glass Surface
This 120W Monitoring Solar Panel delivers stable, reliable off‑grid power supply solution for security camera bulk procurement and large‑scale outdoor surveillance projects. Equipped with top‑grade monocrystalline silicon cells reaching 22.8% conversion efficiency, it provides steady 36V charging power for outdoor monitoring systems under diverse harsh weather conditions. Its heavy‑duty aluminum alloy frame, IP68 dust‑proof & waterproof structure, adjustable mounting bracket and standard MC4 connector (300mm cable length with customizable options) perfectly fit security system installers, engineering contractors and remote site monitoring deployments. With wide‑25℃ ~ +65℃ operating temperature range, strict power temperature coefficient and complete global safety certifications, this 120W solar panel maintains consistent long‑term performance for mass outdoor installation. Custom OEM/ODM service and flexible MOQs are available to match your wholesale business demands.
Core Product Advantages
- High‑Efficiency Mono Silicon Cells – Premium monocrystalline silicon with conversion efficiency up to 22.8%, delivers steady power generation even under low‑light overcast conditions.
- Adjustable Heavy‑Duty Mount Bracket – Custom‑fitted mounting stand enables angle adjustment, orient the solar panel toward sunlight to maximize energy harvesting.
- Rugged Aluminum Alloy Frame – 9.8 kg solid structure, built‑in bracket supports direct wall‑mount or pole‑mount installation for outdoor surveillance sites.
- Stable 36V MC4 Output – Standard MC4 connector with 300 mm cable (customizable length available), max 5.56 A charging current, well‑matched for outdoor monitoring battery‑charge systems.
- IP68 Dustproof & Waterproof Structure – Reinforced high‑transparency tempered glass plus aluminum alloy frame, withstands heavy rain, dust and long‑term outdoor weather erosion.
- Wide‑Temp Reliable Operation – Operates stably from ‑25℃ to +65℃, adapts to freezing cold winters and high‑temperature summer outdoor scenarios.
- Reliable Power Temperature Coefficient –‑0.4%/℃ power temperature coefficient, maintains dependable real‑world output for long‑time field deployment.
- Multi‑Global Safety Certifications – ISO, CE, FCC, RoHS certified, fully compliant for overseas wholesale and engineering‑project exports.
- Excellent Power Tolerance – Strict power tolerance guarantees stable 120W rated output, prevents insufficient power for monitoring equipment.
- We also offer OEM/ODM services bulk wholesale orders of this 5W solar panel.
Package Includes
- 1 × 120W Monitoring Solar Panel
- 1 × Adjustable Heavy‑duty Mounting Bracket
- 1 × 300mm MC4 Output Cable
- 1 × Full Set Mounting Screws & Hardware
- 1 × User Manual (English)
Product & Packaging Specs
- Model: GT‑MSP120
- Material Type: High‑efficiency Monocrystalline Silicon
- Efficiency: 22.8% Top Grade Mono Cells
- Operating Temperature: -25℃ ~ +65℃
- Product Dimensions: 1600 × 800 × 35 mm
- Weight: 9.8 kg
- Cable Length: 300 mm (Customizable available)
- Connector: Standard MC4 Connector
- Max Charging Current: 5.56A
- Protection Class: IP68 Waterproof & Dustproof
- Certifications: ISO, CE, FCC, RoHS
- Special Feature: Heavy‑duty adjustable mounting bracket for wall‑mount & pole‑mount installation
- Low‑light performance: Reliable power generation under cloudy weak‑light environments
- Power Temperature Coefficient: ‑0.4%/℃
Product Specifications
| Item | Parameter | Item | Parameter |
|---|---|---|---|
| Maximum Power | 120W | Maximum Power Voltage | 36V |
| Peak current (Imp) | 5.56A | Open-circuit voltage (Voc) | 43.2V |
| Short-circuit Current(Isc) | 5.88A | Connector Type | Standard MC4 Connector, 300mm cable (customizable) |
| Output Ports | MC4 Male & Female | Power Temperature Coefficient | ‑0.4%/℃ |
| Cell Type | High efficiency mono silicon | Operating Temp | -25℃ ~ +60℃ |
Frequently Asked Questions (FAQs)
Our standard MOQ is 50 units. Mixed‑order with other solar panels, balcony PV kits and energy storage products is supported for bulk orders, which helps you diversify your product portfolio without high single‑SKU inventory pressure.
This panel has passed ISO, CE and RoHS certifications. We can provide full certification files, test reports for your customs clearance and local market compliance inspection.
It is designed for 24‑36V battery charging systems. Widely applied for outdoor CCTV monitoring, site surveillance, small off‑grid energy storage systems. It works well with lead‑acid, gel and lithium‑ion batteries with proper charge controller.
Yes, OEM & ODM services are available. We support custom‑printed logo, custom model naming, adjustable MC4 cable length and neutral‑packing for your private‑label business. Certain MOQ requirements apply for customized solutions.
For standard stock orders, lead‑time is 7‑14 working days. For large container orders or customized orders, lead‑time is 20‑30 working days. Export‑grade carton packaging with foam protection is adopted for sea‑freight to avoid damage during long‑distance transportation.
We offer 10‑year material & workmanship warranty for this solar panel. For wholesale partners, we provide product datasheets, marketing pictures, parameter tables and technical support for your pre‑sales and after‑sales customer service.
Yes. IP68 dustproof & waterproof rating, operating temperature range ‑25℃ ~ +65℃. It adapts to harsh scenarios including outdoor monitoring sites, open‑air yards, cold winter and high‑temperature summer environments. Still suggest installing with proper brackets and avoid long‑term immersion.
This unit is optimized for low‑light power generation and long‑term stable outdoor operation, matched with heavy‑duty adjustable bracket for wall‑mount / pole‑mount monitoring installation. It is more targeted for surveillance, site monitoring and small off‑grid projects, ideal for security‑project integrators and B‑to‑B wholesalers.
